Hey there,
I'm using whaaaat, an inquirer.js clone based on prompt_toolkit to implement an internal CLI for our company. After building a minimal PoC, I found that when using prompt_toolkits HSplit component, the second window passed into the layout initially gets rendered correctly and then jumps to the bottom of the terminal window (see GIF). Also, this only happens when the Inquiry is started within a cleared window. I have already filed an issue at whaaaaat, but thought that you folks may be more suited to give me hint, since this seems to be caused by HSplit.

The library uses the following Layout:

layout = HSplit([
  Window(content=TokenListControl(get_prompt_tokens, align_center=False)),
  ConditionalContainer(
    Window(
      ic,
      width=D.exact(43),
      height=D(min=3),
      scroll_offsets=ScrollOffsets(top=1, bottom=1)
    ),
    filter=~IsDone()
  )
])

where ic is an instance of InquirerControl implemented as follows:

class InquirerControl(TokenListControl):
    def __init__(self, choices, **kwargs):
        self.selected_option_index = 0
        self.answered = False
        self.choices = choices
        self._init_choices(choices)
        super(InquirerControl, self).__init__(self._get_choice_tokens,
                                              **kwargs)

    def _init_choices(self, choices, default=None):
        # helper to convert from question format to internal format
        self.choices = []  # list (name, value, disabled)
        searching_first_choice = True
        for i, c in enumerate(choices):
            if isinstance(c, Separator):
                self.choices.append((c, None, None))
            else:
                if isinstance(c, basestring):
                    self.choices.append((c, c, None))
                else:
                    name = c.get('name')
                    value = c.get('value', name)
                    disabled = c.get('disabled', None)
                    self.choices.append((name, value, disabled))
                if searching_first_choice:
                    self.selected_option_index = i  # found the first choice
                    searching_first_choice = False

    @property
    def choice_count(self):
        return len(self.choices)

    def _get_choice_tokens(self, cli):
        tokens = []
        T = Token

        def append(index, choice):
            selected = (index == self.selected_option_index)

            @if_mousedown
            def select_item(cli, mouse_event):
                # bind option with this index to mouse event
                self.selected_option_index = index
                self.answered = True
                cli.set_return_value(None)

            tokens.append((T.Pointer if selected else T, ' \u276f ' if selected
            else '   '))
            if selected:
                tokens.append((Token.SetCursorPosition, ''))
            if choice[2]:  # disabled
                tokens.append((T.Selected if selected else T,
                               '- %s (%s)' % (choice[0], choice[2])))
            else:
                tokens.append((T.Selected if selected else T, str(choice[0]),
                               select_item))
            tokens.append((T, '\n'))

        # prepare the select choices
        for i, choice in enumerate(self.choices):
            append(i, choice)
        tokens.pop()  # Remove last newline.
        return tokens

    def get_selection(self):
        return self.choices[self.selected_option_index]

Gif with cleared window:

GIF with cleared

Gif without cleared window:

uncleared
