MT7615dn: 5G max power is 6dBm
Nobody has claimed this yet.
- Dominant language
- C
- Stars
- 888
- Forks
- 436
- PR merge metrics
- No merged PRs in 30d
Description
This router is Raisecom MSG1500 X.00, which is customized by China Telecom.
SOC is mediatek mt7621, wifi is a single MT7615DN chipset which provides 2.4G & 5G communication.
The hardware of 5G has a LNA and PA.
Nand flash capacity is 128MB.
After installing openwrt master firmware, 5G configuation shows that max power is 6dBm.
Following is the openwrt version:
root@OpenWrt:~# uname -a
Linux OpenWrt 5.4.142 #0 SMP Tue Aug 31 14:15:59 2021 mips GNU/Linux
root@OpenWrt:~# opkg list | grep mt76
kmod-mt76-connac - 5.4.142+2021-07-15-bbebea7d-4
kmod-mt76-core - 5.4.142+2021-07-15-bbebea7d-4
kmod-mt7615-common - 5.4.142+2021-07-15-bbebea7d-4
kmod-mt7615-firmware - 5.4.142+2021-07-15-bbebea7d-4
kmod-mt7615e - 5.4.142+2021-07-15-bbebea7d-4
root@OpenWrt:~#
Here is the picture:
Factory partion of stock firmware (EEPROM) is:
Contributor guide
No contributing guide indexed for this repository
First steps
- Read the whole issue, then the project's contributing guide.
- Comment on the issue to say you are picking it up — it saves two people doing the same work.
- Fork the repository and make your change on a branch.
- Open a pull request that references the issue number.
Research direction
Start by reproducing the 5G power limit on the Raisecom MSG1500 and inspect the attached EEPROM data alongside the MT7615 power and calibration handling. Done means the device no longer reports a 5G maximum power of 6dBm, with the result validated on the reported hardware.
