Consul Ingress-Gateway example does not work when ACL's are enabled

I have an environment using nomad 0.11.1 and consul 1.8.2. Consul connect works well and services are able to communicate with each other. TLS and ACL's are enabled.

```
consul --version
Consul v1.8.2
Revision ba7d9435e
Protocol 2 spoken by default, understands 2 to 3 (agent will automatically use protocol >2 when speaking to compatible agents)
```

```
envoy --version
envoy version: 923c4111bb48405ac96ef050c4f59ebbad3d7761/1.14.4/clean-getenvoy-2aa564b-envoy/RELEASE/BoringSSL
```

The tutorial for ingress-gateways does not work. The services are unable to communicate. I've ensured that intentions are configured correctly, and that the services are listening on the correct ports.

## Setup counting service
```
consul services register counting.hcl
```

counting.hcl

```
service {
name = "counting"
id = "counting-1"
port = 9003

connect {
sidecar_service {}
}

check {
id = "counting-check"
http = "http://localhost:9003/health"
method = "GET"
interval = "10s"
timeout = "1s"
}
}
```

```
consul connect envoy -sidecar-for counting-1 -admin-bind localhost:19001 > dashboard-proxy.log
```
```
wget https://github.com/hashicorp/demo-consul-101/releases/download/0.0.3/counting-service_linux_amd64.zip
unzip counting-service_linux_amd64.zip
PORT=9003 ./counting-service
```

## Setup Ingress gateway
```
consul config write ingress-gateway.hcl
```

ingress-gateway.hcl

```
Kind = "ingress-gateway"
Name = "ingress-service"

Listeners = [
{
Port = 8080
Protocol = "tcp"
Services = [
{
Name = "counting"
}
]
}
]
```

```
consul connect envoy -gateway=ingress -register -service ingress-service -admin-bind localhost:19002 -address '{{ GetInterfaceIP "eth0" }}:8888'
```

## Setup dashboard
```
wget https://github.com/hashicorp/demo-consul-101/releases/download/0.0.3/dashboard-service_linux_amd64.zip
unzip dashboard-service_linux_amd64.zip
# Note using 127.0.0.1 because running on the same host
PORT=9002 COUNTING_SERVICE_URL="http://127.0.0.1:8080" ./dashboard-service_linux_amd64
```

## Setup Intentions
```
consul intention create -allow ingress-service counting
```

# Troubleshooting

To troubleshoot this I've ensured

- Using bootstrap tokens for all service registrations
- Look at consul logs
- Look at envoy logs
- Able to curl services `curl localhost:9002`, `curl localhost:8080`

I've repeated these steps 5 separate times. Twice using the exact examples in the learning document, and 3 times using the count-dash example shown in the nomad documentation which I have working with consul connect. I've also tried various other nomad jobs in my infrastructure with the same results

- Other ideas

I've also tried changing the service type from `tcp` to `http` with no luck.

Either I'm really bad at following directions, or something is missing from the tutorial.
