Listener drops all connections when per filter config updated with RDS

Open
#17,109 20 comments 1 reaction 0 assignees View on GitHub
area/perf area/xds help wanted investigate
Dominant language
C++
Stars
28.9k
Forks
5.6k
Avg merge
1d 20h
Merged PRs (30d)
437

Description

*Title*: *Listener drops all connections when per filter config updated with RDS*

*Description*:
Having simple working setup:
```
static_resources {
listeners {
name: "listener"
address {
socket_address {
address: "0.0.0.0"
port_value: 8080
}
}
filter_chains {
filters {
name: "envoy.http_connection_manager"
typed_config {
[type.googleapis.com/envoy.extensions.filters.network.http_connection_manager.v3.HttpConnectionManager] {
stat_prefix: "ingress_http"
rds {
config_source {
ads {
}
initial_fetch_timeout {
seconds: 3
}
resource_api_version: V3
}
route_config_name: "xds-config-backend"
}
http_filters {
name: "dropbox.envoy.waf"
typed_config {
[type.googleapis.com/dropbox.envoy_dbx.WafConfig] {
}
}
}
http_filters {
name: "envoy.filters.http.router"
}
// ... less important... //
```
Everything works well, including updates sent by XDS to Envoy while there is no "per vhost filter config overrides" - envoy successfully and without any impact to traffic able to update route configuration.

However, if route configuration **contains** per virtual host overrides, like
```proto
resources: <
[type.googleapis.com/envoy.config.route.v3.RouteConfiguration]: <
name: "xds-config-backend"
virtual_hosts: <
name: "test1"
domains: "test1"
routes: <
match: <
prefix: "/test1"
>
route: <
cluster: "test_cluster"
>
>
typed_per_filter_config: <
key: "dropbox.envoy.waf"
value: <
[type.googleapis.com/dropbox.envoy_dbx.WafConfig]: <
>
>
>
>
```
Listener re-establishing all connections (`downstream_cx_active` gauge):

To me it seems like listener re-creates `HttpConnectionManager` and it somehow causes old connections to close.

Is it expected behavior?
Is there some parameter that we can adjust?
Any other ideas?

I'd be happy to provide more details, if needed.

Thanks
