Description

## Description of bug / unexpected behavior

When using `alignment` in the arguments for `Paragraph` (e.g. `alignment='left'`), character overlap occurs after escaped characters (e.g. `\n`, `\t`). This doesn't occur when omitting the `alignment` argument entirely (although this **still left aligns text** by default - that is to say, omitting `alignment` and using `alignment='left'` should have the same effect but don't).

## Expected behavior

No character overlap after newlines, tabs, etc. when using non-default `alignment` arguments.

## How to reproduce the issue

Code for reproducing the problem

```py
class UsingParagraph(Scene):
def construct(self):
paragraph = Paragraph('nothing', 'With \nNewlines', '\tWith Tabs')

self.play(Create(paragraph))
self.wait()
self.play(Uncreate(paragraph))

paragraph = Paragraph('alignment=""', 'With \nNewlines', '\tWith Tabs', alignment='')

self.play(Create(paragraph))
self.wait()
self.play(Uncreate(paragraph))

paragraph = Paragraph('alignment="left"', 'With \nNewlines', '\tWith Tabs', alignment='left')

self.play(Create(paragraph)) # HERE WE GET THE BUG WITH CHARACTER OVERLAP
self.wait()
self.play(Uncreate(paragraph))

paragraph = Paragraph('alignment="right"', 'With \nNewlines', '\tWith Tabs', alignment='right')

self.play(Create(paragraph)) # THIS WOULD ALSO APPEAR TO BE A VARIATION OF THE BUG
self.wait()
self.play(Uncreate(paragraph))

paragraph = Paragraph('alignment="left", no ligatures', 'With \nNewlines', '\tWith Tabs', alignment='left', disable_ligatures=True)

self.play(Create(paragraph)) # NEWLINES AND TABS ENTIRELY REMOVED BY DISABLE LIGATURES AS EXPECTED
self.wait()
self.play(Uncreate(paragraph))
```

## Additional media files

Images/GIFs

![Output of rendering UsingParagraph scene above](https://user-images.githubusercontent.com/30503695/163378107-bcd215b7-36c3-4c93-a003-c3856501d6f9.gif)

## Additional comments

It's highly likely this bug is related to #2366 and would likely be solved in the rewrite proposed in #2355
