SVGMobject doesn't care for width and height defined in SVG

Open
#1,390 4 comments 0 reactions 0 assignees View on GitHub

Nobody has claimed this yet.

issue:bug SVG
Dominant language
Python
Stars
40.9k
Forks
3.1k
Avg merge
3d 12h
Merged PRs (30d)
25

Description

## Description of bug / unexpected behavior
While playing around with https://github.com/ManimCommunity/manim/pull/1361, I have an SVG, [a4dae70e0eb51266.txt](https://github.com/ManimCommunity/manim/files/6358293/a4dae70e0eb51266.txt), converted to `.txt`, where the width and height element are not taken into account while displaying.

Using Inkscape's, export to png.
![a4dae70e0eb51266](https://user-images.githubusercontent.com/49693820/115717559-e9a18d00-a397-11eb-8713-9185fdfadc74.png)

Trying the same with this Code in Manim
```py
from manim import *
config["background_color"] = WHITE
class HelloWorld(Scene):
def construct(self):
text = SVGMobject('a4dae70e0eb51266.svg')
self.add(text)
```
I get rendering with `manim -psql test.py`
![HelloWorld_ManimCE_v0 5 0](https://user-images.githubusercontent.com/49693820/115717818-2cfbfb80-a398-11eb-891a-98bc07473748.png)

## Expected behavior
What I am expecting is that the PNG rendered using Manim similar to rendered using Manim to match that of Inkscape. With bounding boxes and width and height element matching that of the SVG.

## How to reproduce the issue

Code for reproducing the problem

```py
from manim import *
config["background_color"] = WHITE
class HelloWorld(Scene):
def construct(self):
text = SVGMobject('a4dae70e0eb51266.svg')
self.add(text)
```

## Additional media files

Images/GIFs

![HelloWorld_ManimCE_v0 5 0](https://user-images.githubusercontent.com/49693820/115717818-2cfbfb80-a398-11eb-891a-98bc07473748.png)

## Additional comments
On the other hand, I would like SVGMobject to draw things with the same size as the SVG itself and give a warning or something asking the user's to scale if the SVG has gone out of the screen or something. That would be super helpful for the `Text` and `Tex` objects because the consistency of size would be the size. For example, the `size` parameter will never work as expected with `Text` because the SVG is scaled and not drawn according to the size.
