LineChart with combine charts

I want to draw various line graphs in this combinecharts but the visualization does not fit the line but only a dot at the start point.


//
// ScatterTableViewCell.swift
// Homix
//
// Created by Francesco Stabile on 09/09/21.
//

import UIKit
import Charts

class ScatterTableViewCell: UITableViewCell {
@IBOutlet weak var chartView: CombinedChartView!
var sistolicAvarange = [90,100,120]
override func awakeFromNib() {
super.awakeFromNib()
// Initialization code
}

override func setSelected(_ selected: Bool, animated: Bool) {
super.setSelected(selected, animated: animated)

// Configure the view for the selected state
}

final func setupChart() {
chartView.isUserInteractionEnabled = false
chartView.legend.enabled = false
chartView.rightAxis.enabled = false
chartView.xAxis.drawAxisLineEnabled = false
chartView.xAxis.labelPosition = .bottom
chartView.xAxis.drawGridLinesEnabled = false
chartView.leftAxis.drawAxisLineEnabled = false
setDataCount(24, range: 180)
}
private func setDataCount(_ count: Int, range: UInt32) {
let values1 = (0.. ChartDataEntry in
let val = Double(arc4random_uniform(range) + 3)
return ChartDataEntry(x: Double(i), y: val)
}
let values2 = (0.. ChartDataEntry in
let val = Double(arc4random_uniform(range) + 3)
return ChartDataEntry(x: Double(i) + 0.33, y: val)
}
let values3 = (0.. ChartDataEntry in
let val = Double(arc4random_uniform(range) + 3)
return ChartDataEntry(x: Double(i) + 0.66, y: val)
}
var lineDataSets : [LineChartDataSet] = []
for i in 0...2 {
let value = (0.. ChartDataEntry in
let val = Double(arc4random_uniform(range) + 3)
let chartDataEntry = ChartDataEntry(x:Double(j), y: val)
return chartDataEntry
}
let dataSet = (LineChartDataSet(entries:value, label:"Line\(i)"))
dataSet.setColor(UIColor(red: 240/255, green: 238/255, blue: 70/255, alpha: 1))
dataSet.lineWidth = 2.5
dataSet.setCircleColor(UIColor(red: 240/255, green: 238/255, blue: 70/255, alpha: 1))
dataSet.circleRadius = 5
dataSet.circleHoleRadius = 2.5
dataSet.fillColor = UIColor(red: 240/255, green: 238/255, blue: 70/255, alpha: 1)
dataSet.mode = .cubicBezier
dataSet.drawValuesEnabled = true
dataSet.valueFont = .systemFont(ofSize: 10)
dataSet.valueTextColor = UIColor(red: 240/255, green: 238/255, blue: 70/255, alpha: 1)
dataSet.axisDependency = .left
lineDataSets.append(dataSet)
}

let set1 = ScatterChartDataSet(entries: values1, label: "DS 1")
set1.setScatterShape(.square)
set1.setColor(ChartColorTemplates.colorful()[0])
set1.scatterShapeSize = 8

let set2 = ScatterChartDataSet(entries: values2, label: "DS 2")
set2.setScatterShape(.circle)
set2.scatterShapeHoleColor = ChartColorTemplates.colorful()[3]
set2.scatterShapeHoleRadius = 3.5
set2.setColor(ChartColorTemplates.colorful()[1])
set2.scatterShapeSize = 8

let set3 = ScatterChartDataSet(entries: values3, label: "DS 3")
set3.setScatterShape(.triangle)
set3.setColor(ChartColorTemplates.colorful()[2])
set3.scatterShapeSize = 8
// let data: CombinedChartData = [set1, set2, set3,sistolicLineChart]
let data = CombinedChartData()
data.scatterData = ScatterChartData(dataSets: [set1,set2,set3])
data.lineData = LineChartData(dataSets:lineDataSets)
data.setValueFont(.systemFont(ofSize: 7, weight: .light))
chartView.data = data

}

}
